Multímetro digital, mide voltaje DC/AC, corriente DC/AC, resistencia, temperatura, frecuencia, continuidad y capacitancia. Con medicion de resistencia de aislamiento.
SPECIFICATIONS
| Specifications | Range | Best Accuracy | |
| Model | UT531 | ||
| DC Voltage(V) | 60mV/600mV/6V/60V/600V/1000V | ±(0.09%+6) | |
| AC Voltage(V) | 6V/60V/600V/1000V | ±(1%+30) | |
| DC Current (A) | 60mA/600mA | ±(1.0%+2) | |
| AC Current(A) (50Hz-1kHz) | 60mA/600mA | ±(1.5%+2) | |
| Resistance(Ω) | 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/40MΩ | ±(0.9%+2) | |
| Capacitance (F) | 10nF/100nF/1uF/10uF/100uF | ±(3%+5) | |
| Frequency (Hz) | 60Hz/600Hz/6kHz/60kHz/600kHz/1MHz | ±(0.1%+3) | |
| Insulation Resistance (Ω) |
Test Voltage | 500V/1000V | 0%-10% |
| 500V | 0.5MΩ-99.9MΩ | ±(3%+5) | |
| 100MΩ-500MΩ | ±(3%+5) | ||
| 1000V | 4.0MΩ-99.9MΩ | ±(3%+5) | |
| 100MΩ-600MΩ | ±(3%+5) | ||
| Short-Circuit Current | <2mA | √ | |
GENERAL CHARACTERISTICS
| Features | ||
| Display Count | 60000 | |
| Auto Range | √ | |
| Manual Range | √ | |
| True RMS | √ | |
| Diode | √ | |
| USB Interface | √ | |
| True RMS | √ | |
| Data logging | 99 | √ |
| Continuity Buzzer | √ | |
| Data Hold | √ | |
| Low Battery Indication | √ | |
| Input Impedance for DCV | >10MΩ | √ |
| Power | 1.5V alkaline batteries (LR6)x6 | |
| LCD size | 81mmx46mm | |
Enlace al fabricante
Palabras claves: multimetro, tester, True RMS
| Fabricante | UNI-T |
| Frecuencia | No |
| Diodo | Si |
| RPM | No |
| Duty | No |
| Continuidad | Si |
| NCV | No |
| Beta BJT | No |
| Interfaz Bluetooth | No |
| Interfaz USB | No |
| Tipo de equipo | Portatil |
| Voltaje AC | Si |
| Voltaje DC | Si |
| Corriente AC | Si |
| Corriente DC | Si |
| Resistividad | Si |
| Capacitancia | Si |
| Temperatura | No |
| Selección de rango | Automático |
UT531-English-Manual.pdf
Download
