Este multímetro tiene autorrango, mide voltaje AC/ DC, resistencia, frecuencia, ciclo de dureza, diodo, continuidad.
| Specifications | Range | Best Accuracy |
| Model | UT120C | |
| DC Voltage (V) | 400mV/4V/40V/600V | ±(0.8%+1) |
| AC Voltage (V) | 4V/40V/400V/600V | ±(1.2%+3) |
| DC Current (A) | 400uA/4mA/40mA/400mA | ±(1.0%+3) |
| AC Current (A) | 400uA/4mA/40mA/400mA | ±(1.5%+5) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(1%+2) |
| Capacitance (F) | 4nF/40nF/400nF/4uF/40uF/100uF | ±(4%+3) |
| Frequency(Hz) | 10Hz~100kHz | ±(0.5%+3) |
| Features | ||
| Display Count | 4000 | |
| Auto Range | √ | |
| Diode | √ | |
| Duty Cycle | 0.1%-99.9% | √ |
| Continuity Buzzer | √ | |
| Low Battery Indication | <2.4V | √ |
| Data Hold | √ | |
| Auto Power Off | Around 30 Minutes | √ |
| Input Impedance for DCV | Around 10MΩ | √ |
| Power | 3V Battery (CR2032) | |
Enlace al fabricante:
Palabras claves: multímetro, tester
| Fabricante | UNI-T |
| Frecuencia | Si |
| Diodo | Si |
| RPM | No |
| Duty | Si |
| Continuidad | Si |
| NCV | No |
| Beta BJT | No |
| Interfaz Bluetooth | No |
| Interfaz USB | No |
| Tipo de equipo | Portatil |
| Voltaje AC | Si |
| Voltaje DC | Si |
| Corriente AC | Si |
| Corriente DC | Si |
| Resistividad | Si |
| Capacitancia | Si |
| Temperatura | No |
| Selección de rango | Automático |
UT120 Series Flyer.pdf
Download
